74HC160 Synchronous Decade Counter IC (16-DIP)
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Future Electronics | 74HC160 (Counter) | 20 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 20 EGP
About this product
The 74HC160 is a high-speed CMOS synchronous 4-bit decade (BCD) counter with an asynchronous clear input. It counts up on the positive clock edge and suits digit counting, divide-by-ten frequency division and timing in digital logic projects. It operates from 2 V to 6 V and comes in a 16-pin DIP package.
Specifications
- Type
- Counter, Decade
- Number of bits per element
- 4
- Reset
- Asynchronous
- Timing
- Synchronous
- Count rate
- 66MHz
- Trigger type
- Positive Edge
- Voltage - Supply
- 2V ~ 6V
- Package / Case
- 16-DIP (0.300", 7.62mm)
Frequently asked questions
What is the price of 74HC160 Synchronous Decade Counter IC (16-DIP) in Egypt?
74HC160 Synchronous Decade Counter IC (16-DIP) currently costs 20 EGP in Egypt.
Where can I buy 74HC160 Synchronous Decade Counter IC (16-DIP) in Egypt?
74HC160 Synchronous Decade Counter IC (16-DIP) is available from Future Electronics. Compare the offers above to find the best price.
Can I use the 74HC160 with a 5 V supply?
Yes, 5 V is well within its 2 V to 6 V range. Be aware that 74HC inputs use CMOS thresholds, so signals from 3.3 V logic may not reliably reach a high level at a 5 V supply. Check your signal levels.
Which pins are needed for a basic count?
Pin 16 is VCC, pin 8 is GND, pin 2 is the clock input (CP) and pin 1 is the active-low master reset (MR). Keep MR high for normal counting, keep the count-enable inputs (pins 7 and 10) and parallel enable (pin 9) high, and read the outputs Q0 to Q3 on pins 14, 13, 12 and 11.
