5 mm Pitch 2-Pin PCB Screw Terminal Block
Prices updated: 13 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Circuits Electronics | PCB Terminal Block (5mm-2Pin) | 4 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 4 EGP
About this product
A 2-pin PCB-mount screw terminal block with 5 mm pitch for making removable wire connections to a circuit board. Wires are clamped by tightening an M2.5 screw, which makes temporary or service connections easy. It accepts 22 to 14 AWG (2.5 mm²) wire and is rated 300 V / 250 V and 10 A / 18 A as listed.
Specifications
- Pitch
- 5 mm
- Pins
- 2
- Screw
- M2.5 steel, zinc plated
- Wire range
- 22-14 AWG (2.5 mm²)
- Rated voltage
- 300V / 250V
- Rated current
- 10A / 18A
Frequently asked questions
What is the price of 5 mm Pitch 2-Pin PCB Screw Terminal Block in Egypt?
5 mm Pitch 2-Pin PCB Screw Terminal Block currently costs 4 EGP in Egypt.
Where can I buy 5 mm Pitch 2-Pin PCB Screw Terminal Block in Egypt?
5 mm Pitch 2-Pin PCB Screw Terminal Block is available from Circuits Electronics. Compare the offers above to find the best price.
What wire size can I use?
The terminal accepts 22 to 14 AWG wire, up to 2.5 mm². Strip the insulation and tighten the M2.5 screw firmly.
Can I use it on a breadboard?
No. It is designed for PCB mounting with 5 mm hole spacing. For breadboards, use pin headers or jumper wires instead.
