40EPS12 Input Rectifier Diode 40A 1200V TO-247AC
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Makers ElectronicsCheapest | 40EPS12 High Voltage Input Rectifier Diode 40A 1200V TO-247AC-2L | 90 EGP | View in store |
 UGE | DIODE 40EPS12 40A 1200V TO247 | 251 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 90 EGP
About this product
The 40EPS12 is a 40 A, 1200 V input rectifier diode in a TO-247AC-2L package. It is used in high-voltage rectifier stages such as power supply and motor drive inputs, with a maximum junction temperature of 150 °C.
Specifications
- Repetitive peak reverse voltage
- 1200 V
- Average forward current
- 40 A
- Package
- TO-247AC-2L
- Maximum junction temperature
- 150 °C
- Type
- Input rectifier diode
Frequently asked questions
What is the price of 40EPS12 Input Rectifier Diode 40A 1200V TO-247AC in Egypt?
40EPS12 Input Rectifier Diode 40A 1200V TO-247AC currently costs between 90 and 251 EGP across 2 offers in Egypt.
Where can I buy 40EPS12 Input Rectifier Diode 40A 1200V TO-247AC in Egypt?
40EPS12 Input Rectifier Diode 40A 1200V TO-247AC is available from Makers Electronics and UGE. Compare the offers above to find the best price.
Does it need a heatsink?
At high currents, yes. TO-247 packages are normally mounted on a heatsink with thermal compound. Check the datasheet for thermal resistance and whether the tab is electrically connected to the cathode before sharing a heatsink.
Is its voltage rating suitable for mains rectification?
The 1200 V reverse rating is above the peak voltage of a 230 V AC mains supply (about 325 V), so the voltage margin is large. Confirm the full design, including surge and current requirements, before using it.
