2SC2383 NPN Transistor TO-92L (160V, 1A)
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Makers Electronics | 2SC2383 NPN TO-92 Bipolar Transistors – BJT | 2 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 2 EGP
About this product
The 2SC2383 is a high-voltage NPN bipolar transistor in a TO-92L package, rated for 160V VCEO and 1A continuous collector current. Its DC current gain of 60 to 320 suits switching loads up to 1000 mA, motor controllers and audio amplifier stages, and it is used in color TV circuits.
Specifications
- Transistor type
- NPN
- Collector-emitter voltage, max (VCEO)
- 160 V
- Collector-base voltage, max (VCBO)
- 160 V
- Emitter-base voltage, max (VEBO)
- 6 V
- Collector current, continuous max
- 1 A
- Collector dissipation
- 0.9 W
- DC current gain (hFE)
- 60 – 320
- Transition frequency, min
- 100 MHz
Frequently asked questions
What is the price of 2SC2383 NPN Transistor TO-92L (160V, 1A) in Egypt?
2SC2383 NPN Transistor TO-92L (160V, 1A) currently costs 2 EGP in Egypt.
Where can I buy 2SC2383 NPN Transistor TO-92L (160V, 1A) in Egypt?
2SC2383 NPN Transistor TO-92L (160V, 1A) is available from Makers Electronics. Compare the offers above to find the best price.
Can a microcontroller pin drive the 2SC2383 directly?
Not for loads. A microcontroller pin supplies only a few milliamps, so use a base resistor sized for the collector current you need. Add a flyback diode across inductive loads such as motors or relays.
Which transistor is its complement?
The 2SA1013 is the PNP counterpart commonly used with the 2SC2383 in complementary pairs. The 2SC2383 has a higher transition frequency (minimum 100 MHz) than the 2SA1013 (15 MHz).
