27C1024 1Mbit (64K x 16) UV EPROM IC DIP-40
Prices updated: 13 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Makers Electronics | 27C1024 1Mbit (64K x 16) UV EPROM IC DIP-40 | 60 EGP | View in store |
Price history
Lowest daily price, last 90 days
Lowest price recorded: 60 EGP
About this product
The 27C1024 is a 1 Mbit UV-erasable EPROM organized as 64K x 16 and read over a parallel bus. It has a 35 ns access time and a 40-pin windowed ceramic DIP package. Used in embedded and computer designs to store firmware that is erased under ultraviolet light and reprogrammed with an EPROM programmer.
Specifications
- Density
- 1 Mbit
- Organization
- 64K x 16
- Access time
- 35 ns
- Supply voltage
- 5 V ±10%
- Interface
- Parallel
- Package
- 40-pin windowed ceramic DIP
Frequently asked questions
What is the price of 27C1024 1Mbit (64K x 16) UV EPROM IC DIP-40 in Egypt?
27C1024 1Mbit (64K x 16) UV EPROM IC DIP-40 currently costs 60 EGP in Egypt.
Where can I buy 27C1024 1Mbit (64K x 16) UV EPROM IC DIP-40 in Egypt?
27C1024 1Mbit (64K x 16) UV EPROM IC DIP-40 is available from Makers Electronics. Compare the offers above to find the best price.
How do I erase this EPROM?
Expose the quartz window to UV light, typically around 15 to 20 minutes with a UV eraser. Afterwards it can be reprogrammed with an EPROM programmer. Cover the window with an opaque label after programming to prevent accidental erasure.
Can it be programmed in-circuit like a flash chip?
No. It needs a dedicated EPROM programmer and is not reprogrammed in-circuit the way a flash memory chip is.
