1N5399 Rectifier Diode 1.5A 1000V Axial
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Makers ElectronicsCheapest | 1N5399 Diode 1.5A 1000V | 0.65 EGP | View in store |
 Microohm | 1N5399 Diode | 1 EGP2 | View in store |
| Circuits Electronics | 1N5399 (Diode 1.5 A -1000V) | 2.5 EGP | View in store |
 Future Electronics | Diode 1N5399 | 3 EGP | View in store |
Price history
Lowest daily price, last 90 days
Lowest price recorded: 0.65 EGP
About this product
The 1N5399 is a general-purpose silicon rectifier diode rated at 1.5 A average forward current and 1000 V peak reverse voltage, in an axial through-hole package. It is used for AC-to-DC conversion and reverse polarity protection in power circuits. It is not intended for fast switching or high-frequency rectification.
Specifications
- Type
- General purpose rectifier
- Average forward current
- 1.5 A
- Peak reverse voltage
- 1000 V
- Package
- Axial, through-hole
- Material
- Silicon
Frequently asked questions
What is the price of 1N5399 Rectifier Diode 1.5A 1000V Axial in Egypt?
1N5399 Rectifier Diode 1.5A 1000V Axial currently costs between 0.65 and 3 EGP across 4 offers in Egypt.
Where can I buy 1N5399 Rectifier Diode 1.5A 1000V Axial in Egypt?
1N5399 Rectifier Diode 1.5A 1000V Axial is available from Makers Electronics, Microohm, Circuits Electronics, and Future Electronics. Compare the offers above to find the best price.
How do I identify the cathode?
The cathode is marked with a band at one end of the body. Current flows from anode to cathode in forward bias, so when used in a rectifier the banded end goes toward the positive DC output.
Can I use it for mains rectification?
Yes, for 50/60 Hz mains rectification in low-current power supplies, since its 1000 V reverse rating is well above the peak of a 220–230 V AC line. Keep the 1.5 A average current limit in mind and add heatsinking or current limiting for higher loads.
