12V DC Solenoid Valve 3/4 Inch, Normally Closed
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Future Electronics | Solenoid Valve for Fluid Control (3/4 Inch) | 220 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 220 EGP
About this product
A 3/4-inch normally closed solenoid valve powered by 12 V DC, with filter screens on its inlet and outlet ports. It is used to switch fluid flow automatically, for example in automatic fluid circulation projects. The body is stainless steel and POM, rated for fluids up to 120 °C and a pressure range of 0.02–0.8 MPa.
Specifications
- Working voltage
- DC 12 V
- Maximum current
- 500 mA
- Operating mode
- Normally closed
- Port size
- 3/4 inch (19 mm external diameter)
- Body material
- Stainless steel / POM
- Maximum fluid temperature
- 120 °C
- Pressure range
- 0.02–0.8 MPa
Frequently asked questions
What is the price of 12V DC Solenoid Valve 3/4 Inch, Normally Closed in Egypt?
12V DC Solenoid Valve 3/4 Inch, Normally Closed currently costs 220 EGP in Egypt.
Where can I buy 12V DC Solenoid Valve 3/4 Inch, Normally Closed in Egypt?
12V DC Solenoid Valve 3/4 Inch, Normally Closed is available from Future Electronics. Compare the offers above to find the best price.
How do I control it from an Arduino?
The coil draws up to 500 mA at 12 V, more than a microcontroller pin can supply. Switch it with a relay module or a MOSFET driver powered from a 12 V supply, and fit a flyback diode across the coil.
What does normally closed mean?
The valve stays closed when no voltage is applied and opens when the 12 V DC supply energizes the coil.
